Name: Capacitive Proximity Switch Level Sensor For 200°C High Temperature, Suitable For Hot Melt Glue Machines, 24V
Brand: Xi 'an Qinwei Instrument Factory (General Partnership Enterprise)
SKU: WKCH2 series
Availability: InStock

Home Products Pressure Transmitter

Capacitive Proximity Switch Level Sensor For 200°C High Temperature, Suitable For Hot Melt Glue Machines, 24V

Product Details:

Brand Name:	QINWEIYB
Model Number:	WKCH2 series

Payment & Shipping Terms:

Minimum Order Quantity:	1Set
Price:	Negotiable
Packaging Details:	Carton or wooden box
Delivery Time:	5-8 work days
Payment Terms:	Western Union,T/T,D/P,D/A,L/C
Supply Ability:	100PCS/Month

Contact Now

Detailed Product Description

Medium:	Oil-based Glue And Other Fluids	Working Voltage:	DC12~24V
Protection:	Reverse, Overload, Short Circuit	Current:	<25mA
Probe Output:	1M FEP Coaxial Cable	Probe Material:	316L + Teflon
Control Box Material:	ABs	Output Function:	NPN + PNPAlways Open Andclosed
Response Time:	<1s	Detection Medium Temperature:	-40-160°c
Highlight:	capacitive proximity switch for hot melt glue machines , high temperature level sensor 200°C , 24V capacitive proximity switch with warranty

Capacitive proximity switch level sensor for 200°C high temperature, suitable for hot melt glue machines, 24V

Product Parameters

Dispenser model: WKCH2 series

Medium: oil-based glue and other fluids

Working voltage: DC12~24V

Protection: reverse, overload, short circuit

Current: <25mA

Probe output: 1M FEP coaxial cable

Probe material: 316L + Teflon

Control box material: ABs

Output function: NPN + PNPAlways open andclosed

Response time: <1s

Detection medium temperature: -40-160°c

Indicator light: Green(Output)
Red
(Power supply)

Product Features:

The probe is made of PEEK/Teflon material, with a maximum temperature resistance of 250°C and excellent resistance to oil, acids, and alkalis.
The modular amplifier board features a one-button SET calibration function and red/green indicator lights for status feedback.
Capacitive sensing enables measurement of non-conductive high-temperature media such as oils, adhesives, and viscous slurries.

Application scenarios

Fryer / Chicken Fryer: High-temperature oil level sensor and fryer oil level probe for detecting cooking oil level and automatic oil replenishment
Hot Melt Glue Machine / PUR Adhesive Machine: Hot melt adhesive level sensor and high-temperature glue level switch for monitoring high-temperature viscous adhesives and solid glue levels
Industrial General Use: High-temperature resistant capacitive level switch, acid and alkali corrosion-resistant liquid level sensor
